Endomycorrhiza and PseudoEctomycorrhiza Produced in vitro by Two Species of Tuber on Transformed Cistus incanus Roots
- 1. Department of Life, Health and Environmental Sciences, University of L’Aquila, Italy
- 2. Department of Life Sciences, Ben-Gurion University of the Negev, Israel
Abstract
The ability of mycelial strains of Tuber borchii and T. melanosporum to produce either ecto- or endomycorrhiza with two clones of transformed roots of Cistus incanus was studied in vitro in relation to nitrogen and phosphate concentrations in the culture medium. While differing in their response to the Cistus clones at particular P and N concentrations, both Tuber species displayed the ability to form endomycorrhiza and pseudo-ectomycorrhiza without Hartig net; however, typical ectomycorrhiza with mantle and Hartig net was not obtained. These results support the notion that Tuber can produce different types of mycorrhiza depending on external conditions.
Keywords
• In vitro mycorrhizal synthesis
• Transformed roots
• Mutualism
• Truffle
CITATION
Pacioni G, Ragnelli AM, Aimola P, Leonardi M, Marinucci D, et al. (2014) Endomycorrhiza and Pseudo-Ectomycorrhiza Produced In vitro by Two Species of Tuber on Transformed Cistus incanus Roots. Int J Plant Biol Res 2(4): 1021.
ABBREVIATIONS
VAM: Vesicular-Arbuscular mycorrhizas; ECM: Ectomycorrhiza; EM: Endomycorrhiza; EEM: Ectendomycorrhiza; IAA: Indole 3-Acetic Acid; MMN: Melin And Norkrans Medium; TR: Cistus incanus Transformed Roots; Ps-ECM: PseudoEctomycorrhiza
INTRODUCTION
The notion that the majority of land plants are completely dependent on symbiotic microorganisms for growth and survival is now well established, highlighting the importance of soil microbes as regulators of plant diversity and abundance [1]. Among the various symbiotic associations discovered so far, the one linking roots and fungi – the mycorrhiza – is very widespread and is considered to be the determining factor in the evolution of land plants [2,3].
Several types of mycorrhizas have been described, and different systems of mycorrhizal classification have been proposed based on their anatomy [4,5]. Increasingly, however, results of in vitro experiments [6,7] and field and greenhouse observations [8], coupled with the new picture of the phenomenon in nature revealed by molecular identification tools [9], support the idea that there are basically just two classes of mycorrhiza: 1) those produced by the aseptate mycelia of species belonging to the Glomerulomycota and Mucoromycotina [10], usually referred to as vesicular-arbuscularmycorrhizas (VAM) in view of the structures formed inside the host cells – although some Endogonaceae can also produce ectomycorrhizas [11]; 2) mycorrhizas produced by the septate mycelia of septomycetes, that is, members of the Ascomycota and Basidiomycota.
Ectomycorrhizas (ECMs) are particularly widespread among the septomycetes and have been extensively studied for their role in forest ecosystems. They were discovered in the late nineteenth century (1885) by B. Frank and were the first form of mycorrhizal symbiosis to be described. In an ectomycorrhiza the fungal hyphae completely cover the root tip, forming a mantle (mycoclena) from which they penetrate the apoplastic spaces of the cortical layers of cell wall surfaces [12].
The genus Tuber (Ascomycota, Pezizales), from which our earliest knowledge about mycorrhizas was derived [13], has long been considered a typical ectomycorrhizal fungus. However, molecular tools [9] have revealed that certain fungal species hitherto considered to be exclusively ectomycorrhizal (including Tuber species) may produce septateendomycorrhizas (orchid mycorrhiza, OM) with the achlorophyllic orchid Neottia. This has been repeatedly confirmed with other species of orchids, including chlorophyllic species [14], and with other plants such as Ericaceae[15].
The possibility of obtaining two or even three different types of mycorrhiza in vitro –ectomycorrhiza (ECM), endomycorrhiza (EM), and ectendomycorrhiza (EEM) – was already known from studies conducted with Terfezia spp, (desert truffles) which form both ectomycorrhizas characterized by a Hartig net [6,16]and septateendomycorrhizas with hyphae penetrating into cortical host cells, in both cases without a hyphal mantle [6,17]. As the former are observed under rich nutritional conditions while the latter occur on media poor in phosphorus [6], it would appear that the nutritional status of the host plant determines which type of mycorrhiza will develop. The notion that the phosphate status of a plant affects mycorrhizal synthesis is well established [18]. It seems that P deficient plant roots exude a greater range and volume of substances to their environment, probably due to increased permeability of the plasma membranes [19]. It has lately been shown that P deficient Arabidopsis plants are characterized by an increased sensitivity to auxin [20]. Auxins have long been known to be implicated in ectomycorrhizal formation. More especially, they have been shown to play a role in the morphological changes that roots undergo during mycorrhiza formation [21]. It has been demonstrated that a fungal mutant overproducing indole 3-acetic acid (IAA) forms three to five times more mycorrhiza than a wild-type mycelium [22]. In some instances, such a mutant has been reported to form ectendomycorrhiza characterized by intracellular penetration and Hartig net [23]. External auxin level has also been shown to play a role in determining the type of mycorrhiza produced [7].
Less studied is the effect of nitrogen concentrations on the determination of mycorrhizal types: Haug et al. [24] working on mycorrhizas of Pisolithus tinctorius in Picea abies roots showed that high concentrations of either nitrate or ammonia resulted in a diminished Hartig net and in hyphal penetration into cortical cells. Brunner and Scheidegger [25] studying colonization of the same plant species by Hebeloma crustuliniforme reported thatNH3 concentrations in excess of 30 mM caused a similar shift in mycorrhizal morphology, namely from the known wild type ectomycorrhiza to an atypical endomycorrhiza. Lately, FloresMonterroso et al. [26] demonstrated that either excess of NH3 or its deficiency, altered gene expression and ectomycorrhiza stability in maritime pine roots.
In the study reported below, we examined the types of mycorrhizal association formed in vitro by Tuber borchii Vittad. and Tuber melanosporum Vittad. With two transformed roots clone of Cistus incanus L. in relation to diverse external nitrogen and, to some extent, phosphate concentrations, using an in vitro culture system. In vitro culture systems offer a controlled environment in which the mechanisms involved in the morphogenesis of mycorrhizas may conveniently be explored, as demonstrated by Ventura et al. [27] and Zaretsky et al. [7].
MATERIALS AND METHODS
Tuber cultures
Tuber melanosporum strain 1015 and Tuber borchii strain ATCC96540 mycelia were sub cultured routinely on modified Melin and Norkrans (MMN) medium at 25°C for 40 days.
Cistus incanus transformed roots
For mycorrhization, we employed two clones of Cistus incanus transformed roots (TR) previously used by [7], namely M2 and W51. These were subcultured for 60 days at 25°C on N5 medium (MS medium with 20% of the amount of nitrates), solidified with 0.2% Phytagel adjusted to pH 5.8 before autoclaving and supplemented with 500 mg l-1 ampicillin.
Mycorrhization
M medium was used to obtain mycorrhizal synthesis based on the results of Wenkart et al. [32] and Zaretsky et al. [7]. TRs were transferred to Falcon 50 ml tubes containing 30 ml of medium for all experiments.
Transformed roots were allowed to grow for 3 weeks before inoculation. A cube of MMN agar containing the Tuber mycelium was then added to each TR containing tube. The co-cultures were kept in the dark at 25°C for 2-4 months prior to examination.
Experimental design
The following formulations of M medium were tested:
- original minimal M medium (4.8 mg/ l KH2 PO4 and 80 mg/l KNO3 )
- M medium modified with respect to phosphorus concentration: low P (0.96 or 0.48 mg/l KH2 PO4 )
- M medium modified with respect to nitrogen concentration: low N (20.2, 80, or 101.1 mg/l KNO3 ), and high N (404 or 606 mg/l KNO3 ).
Both basic and modified M media were gelled with 0.7% Plant Agar (Sigma) adjusted to pH 5.5 before autoclaving.
Each test was performed with at least five samples.
Microscopy
Fungal mycorrhizal colonization of the roots after 2-4 months was assessed by staining with cotton blue (0.1% methyl blue in Amman lactophenol). Prior to staining, each sample was cleared by heating in 10% KOH for 15-30 min in a warm bath (60°C). Next, it was then washed in 0.1 N HCl and bidistilled water, placed in cotton blue, and heated to boiling, then rinsed in lactophenol and observed in the same liquid, or embedded in the resin Tissue-Tek OCT (Sakura) and then deep frozen at -20ºC.
Sections of 12 µm were obtained using a cryostat and observed in lactophenol with a Leitz DMRB microscope.
RESULTS
The results of the mycorrhization experiments are presented in (Table 1). They may be summarized as follows:
Effect of varying the N concentration from 20 to 606 mg/l
P 4.8, N 20.2: the two truffle species react in the same way, each forming endomycorrhiza (Figure 1a) with clone M2 and pseudo-ectomycorrhiza (Figure 1b,c) with clone W51, i.e. both exhibit differential responses to the TR clones
Medium (mg/l) |
TR |
Mycorrhizal type |
||
P |
N |
|
T. melanosporum |
T. borchii |
4.8 |
20.2 |
M2 |
ENDO |
ENDO |
|
|
W51 |
Ps-ECM |
Ps-ECM |
4.8 |
80 |
M2 |
ENDO |
ENDO |
|
|
W51 |
ENDO |
ENDO |
4.8 |
101.1 |
M2 |
None |
Ps-ECM |
|
|
W51 |
None |
Ps-ECM |
4.8 |
404 |
M2 |
None |
ENDO |
|
|
W51 |
None |
ENDO |
4.8 |
606 |
M2 |
None |
ENDO |
|
|
W51 |
None |
ENDO |
0.96 |
80 |
M2 |
ENDO |
Ps-ECM |
|
|
W51 |
Ps-ECM |
Ps-ECM |
0.48 |
80 |
M2 |
ENDO |
Ps-ECM |
|
|
W51 |
Ps-ECM |
Ps-ECM |
Abbreviations: TR: Transformed Roots; ENDO: septate endomycorrhiza; Ps-ECM: pseudo-ectomycorrhiza; None: no growth of mycelium and/or mycorrhizal symbiosis
Table 1: Types of mycorrhiza formed by Tuber melanosporum and Tuber borchii with transformed roots (TR) of two clones of Cistus incanus (M2 and W51) under various concentrations of nitrogen (N) and phosphate (P). ENDO - septate endomycorrhiza; Ps-ECM - pseudo-ectomycorrhiza; none -no growth of mycelium and/or mycorrhizal symbiosis.
Figure 1 Types of mycorrhiza produced in vitro by Tuber strains cultivated with transformed roots of Cistus incanus: (A) – Septate endomycorrhiza; (B) – Squash of a pseudo-ectomycorrhiza; (C) – Thin section of a pseudo-ectomycorrhiza lacking any visible true Hartig net. Bar 50 µm.
P 4.8, N 80 (original M medium): the two truffle species produce endomycorrhiza with both TR clones, i.e. they react in the same way to both clones.
P 4.8, N ranging from 101 to 606: T. melanosporum does not enter into mycorrhizal relations at all while T. borchii does, with endomycorrhiza predominating. The differences observed are between fungal species.
Effect of varying the P concentration from 4.8 to 0.48 or 0.96 mg/l
At P 0.48 or 0.96, N 80, T. melanosporum reacts differently to each of the root clones, forming endomycorrhiza with M2 but PsECM with W51. T. borchii consistently forms Ps-ECM mycorrhiza with both root clones. In this situation, differences were found both between fungal species and between root clones.
DISCUSSION
Our main finding is that both fungal species proved capable of forming septate endomycorrhiza on both Cistus incanus transformed root clones, given appropriate conditions (Table 1, Figure 1a). On the other hand, in none of the experiments performed in this study was a true ectomycorrhiza formed by either fungal species on either clone. This is surprising in view of the finding that, under appropriate conditions, Terfezia spp did form such associations in vitro with clone W51 [7], and so did T. melanosporum with clone L2A; we note that the latter clone is no longer available. The reasons for the discrepancy are unknown at the moment, though it seems reasonable to suppose that they reflect differences between the clones. To be certain of our result the roots in this study were most scrupulously analyzed. However, underdeveloped ectomycorrhizal relations have been described before. Malajczuk et al. [29] described in detail what they termed ‘superficial ectomycorrhiza’ in which fungal hyphae of two different species never penetrated the cortex of the Eucalyptus species studied. Brundrett [4] analyzed ectomycorrhizal forms and also reported epidermal or superficial forms. We believe that the term ‘pseudo-ectomycorrhiza’ best describes our findings, as no true penetration of hyphae into apoplastic spaces between root cells was observed.
Clone M2 differs from Clone W51 mainly in its greater sensitivity to external auxins [7]. The only instances where mycorrhizal type differed between the two clones resulted in the formation of endomycorrhiza with clone M2, suggesting that under these two controlled conditions (4.8 mg/ml P and 20.2 mg/ml N, as well as 0.48 P and 80 N) the differential response of the two clones may have stemmed from differences in auxin excretion by the two fungal species. As auxin secretion levels were not measured in this research, this must be seen as an assumption at this time.
Analysis of the different responses of the two fungal species leads us to conclude that T. melanosporum is more sensitive to high nitrogen concentration than T. borchii. Indeed, T. melanosporum failed to form any kind of association with either root clone when N concentration reached 101 mg/ml or higher, while T. borchii did produce mycorrhiza at these levels, whether ENDO or Ps-ECM.
CONCLUSION
Above we described conditions that support in vitro formation and maintenance of endomycorrhizal associations of two Tuber species with transformed roots of Cistus incanus. Indeed, the most interesting conclusion to be drawn from this study seems to be that, under suitable conditions, any ectomycorrhizal fungus may be capable of forming an underdeveloped type of septate endomycorrhiza [7,8,13,16,22,30].
ACKNOWLEDGEMENTS
We are grateful to Dr. G. Chevalier, INRA, Clermont-Ferrand, France and to Prof. A. Zambonelli, University of Bologna, Italy, for kindly donating the strains of Tuber melanosporum and T. borchii used here.
